High-Speed Dual Band Adapter for Better Connections
The Archer T2U Nano receives Wi-Fi signals on two separate bands. Supporting 256QAM technology increases 2.4GHz data rate from 150Mbps to 200Mbps for 33% faster performance. 433Mbps on 5GHz is ideal for HD video streaming and lag-free online gaming, while 200Mbps on 2.4GHz is perfect for normal use such as web surfing with legacy devices.
Miniature Design - Plug in and forget
With its miniature size and sleek design, users can insert the nano adapter into any USB port and leave it there, no matter when they are traveling or at home.
Travel size and Wi-Fi Roaming - Great Choice for mobile surfing
Growing public Wi-Fi services comes with one inconvenience – you might have to repeatedly select and connect to different Wi-Fi networks while moving.
Archer T2U Nano supports Wi-Fi Roaming that helps your devices connect to the most suitable Wi-Fi automatically as you move, ensure your network is uninterrupted, and with its small, travel-size, Archer T2U Nano is undoubtedly a great choice for mobile surfing.
| Connectivity technology | Wireless | Host interface | USB | USB version | 2.0 | Maximum data transfer rate | 433 Mbit/s | Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x | Wi-Fi | Y | Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) | Frequency range | 2.4 - 5 GHz | Top Wi-Fi standard | Wi-Fi 5 (802.11ac) | Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) | WLAN data transfer rates supported | 11,54,150,200,433 Mbit/s | Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, COFDM, DBPSK, DQPSK, OFDM | Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK | Bandwidth (first) | 2.4 GHz | Bandwidth (second) | 5 GHz | Internal | N | Product colour | Black | Antenna | Y | Antenna design | Internal | Antenna direction type | Omni-directional | Receiver sensitivity | 5GHz:
11a 6Mbps: -90dBm
11a 54Mbps: -73dBm
11n HT20 MCS0: -89dBm
11n HT20 MCS7: -70dBm
11n HT40 MCS0: -86dBm
11n HT40 MCS7: -67dBm
11ac VHT80 MCS0: -82dBm
11ac VHT80 MCS9: -56dBm
2.4GHz:
11b 1Mbps: -96dBm
11b 11Mbps: -88dBm
11g 6Mbps: -89dBm
11g 54Mbps: -74dBm
11n HT20 MCS0: -89dBm
11n HT20 MCS7: -72dBm
11n HT40 MCS0: -86dBm
11n HT40 MCS7: -66dBm | Certification | CE, FCC | USB powered | Y | Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows XP | Mac operating systems supported | macOS | Linux operating systems supported | Y | Operating temperature (T-T) | 0 - 40 °C | Storage temperature (T-T) | -40 - 70 °C | Operating relative humidity (H-H) | 10 - 90% | Storage relative humidity (H-H) | 5 - 90% | Sustainability certificates | RoHS | Width | 15 mm | Depth | 7.1 mm | Height | 18.6 mm | Quantity | 1 | Package width | 138 mm | Package depth | 128 mm | Package height | 30 mm | Package weight | 90 g | Quick installation guide | Y | Transmit power range | 20 - 20 dBmW |
|
|
