Part Number(s):
IntelliTouch Dual Touch (clear) - E326202
TouchPro PCAP (clear with anti-friction) - E304029 Enclosure Color:
Black Touch Technology & Capacity:
SAW (IntelliTouch® Surface Acoustic Wave) - Dual Touch
PCAP (TouchPro® Projected Capacitive) - 10 Touch Touch Interface:
USB Diagonal Size:
31.5'' diagonal, Active matrix TFT LCD (LED) On Screen Display: - Accessible through switches on the OSD Control Remote accessory.
- Controls (side): Menu, Up, Down, Select
- Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Volume, Mute, Recall Defaults, Video Source
- Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
- Lockouts: OSD, Power
- RTC Settings: The clock/time and the monitor ON/OFF schedule can be changed within this menu. Daylight Saving time is adjusted for automatically and will change the current time by one hour to accommodate daylight savings time.
- See user manual for full details.
Aspect Ratio:
16:9 Active Area (mm):
IntelliTouch Dual Touch: 27.57" x 15.54" / 700.4mm x 394.85mm
PCAP: 27.57" x 15.54" / 700.4mm x 394.9mm Resolution:
1920 x 1080 Other Supported Resolutions: - 640 x 480 at 60Hz
- 800 x 500 at 60Hz
- 800 x 600 at 56/60Hz
- 1024 x 768 at 60Hz
- 1280 x 720 at 60Hz
- 1280 x 960 at 60 Hz
- 1280 x 1024 at 60Hz
- 1360 x 768 at 60 Hz
- 1366 x 768 at 60 Hz
- 1440 x 900 at 60 Hz
- 1600 x 1200 at 60 H
- 1680 x 1050 at 60 Hz
- 1920 x 1080 at 60 Hz
Viewing Angle:
Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total Number of Colors:
16.7 million Brightness (typical): - LCD panel: 500 nits
- IntelliTouch Dual Touch: 450 nits
- PCAP: 425 nits
Response Time-total (typical):
8 msec Contrast Ratio:
3000:1 Input Video Format:
Analog VGA, HDCP-capable HDMI 1.3 Input Video Signal Connector:
Female DE-15 VGA, HDMI Type A Receptacle Connector Input Video Frequency:
Horizontal: 31 - 75 KHz
Vertical: 47 - 63 Hz Power Supply:
Internal AC Input Voltage:
AC: 100-240 VAC, 50/60 Hz Input Connector:
AC: IEC 60320 C14 Maximum Operating Time:
24 hours/day Power Consumption (Typical):
Monitor + AC/DC adapter - (Typical @ 120V at 60Hz) ON: IntelliTouch - 47.4W / PCAP - 47.9W, SLEEP: IntelliTouch - 1.1W / PCAP - 0.9W, OFF: 0.1W
- (Typical @ 230V at 50Hz) ON: 47.1W, SLEEP: IntelliTouch - 1.1W / PCAP - 1.0W, OFF: 0.1W
Dimensions:
IntelliTouch: 29.0" x 17.4" x 2.25" / 736.4mm x 443mm x 57.2mm
PCAP: 29.42" x 17.82" x 2.1" / 747.3mm x 452.7mm x 55mm Shipping Box Dimensions:
39.0" x 26.4" x 11.65" / 992mm x 672 mm x 296mm Weight (Unpackaged):
IntelliTouch: 26.7 lbs / 12.1 kg
PCAP: 24.6 lbs / 11.2 kg Weight (Packaged):
IntelliTouch: 41.1 lbs / 18.6 kg
PCAP: 39 lbs / 17.7 kg Operating Temperature:
0°C to 40°C / 32°F to 104°F Storage Temperature:
-20°C to 60°C / -4°F to 140°F Humidity:
Operating: 20% to 80%
Storage: 10% to 90% Sealability:
Touchscreen sealed to bezel
Touchscreen sealed to LCD MTBF:
50,000 hours demonstrated Warranty:
3-year Mounting Options:
400mm x 200mm VESA 4-hole mounting interface on rear of unit
Side mounting brackets included (with IntelliTouch Dual Touch models only) |
