The LevelOne FCS-3306 Fixed Dome Outdoor Camera offers a highly reliable, cost-effective outdoor IP surveillance solution in a low-profile dome mounted casing, which is rated at IP68 and able to withstand outdoor operating conditions such as rain, snow, extreme heat, dust and humidity. The FCS-3306 offers 3-Megapixel resolution, and with 802.3af standard PoE, can use a single Cat.5 cable to run both power and data, making deployments easy and flexible. The dome mounting prevents malicious tampering with the camera, making it a secure and smart choice for all outdoor installations.
| | Type | IP security camera | | Placement supported | Indoor & outdoor | | Connectivity technology | Wired | | Wide Dynamic Range (WDR) | Y | | Day/night mode | Y | | Infrared (IR) cut-off filter | Y | | Certification | CF/FCC/UL | | Mounting type | Ceiling/wall | | Product colour | White | | Form factor | Dome | | LED indicators | Power | | Protection features | Vandal proof | | International Protection (IP) code | IP68 | | IK code | IK10 | | Country of origin | Taiwan | | Field of view (FOV) angle | 129° | | Camera shutter speed | 1 - 100000 s | | Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") | | Number of lenses | 1 | | Maximum aperture number | 1.8 | | Fixed focal length | 2.1 mm | | Night vision | Y | | Night vision distance | 30 m | | LED type | IR | | Maximum resolution | 2048 x 1536 pixels | | Total megapixels | 3 MP | | Video formats supported | RAW | | Video compression formats | H.264, H.265, M-JPEG | | Supported graphics resolutions | 320 x 240, 640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA) | | Frame rate | 30 fps | | Ethernet LAN | Y | | Wi-Fi | N | | Bluetooth | N | | Ethernet interface type | Fast Ethernet | | Networking standards | IEEE 802.3af | | Supported network protocols | IPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, QoS, SNMP, IEEE 802.1X | | Number of users | 16 user(s) | | Quality of Service (QoS) support | Y | | Built-in HDD | N | | Card reader integrated | Y | | Compatible memory cards | MicroSDHC, MicroSDXC | | Ethernet LAN (RJ-45) ports | 1 | | DC-in jack | Y | | Interface | RJ-45 | | Password protection | Y | | Password protection type | User | | IP address filtering | Y | | HTTPS encryption | Y | | Alert notification type | E-mail | | Reset button | Y | | Power source type | PoE | | Power consumption (Power over Ethernet (PoE)) | 12.95 W | | DC output voltage | 12 | | Power over Ethernet (PoE) | Y | | Operating temperature (T-T) | -40 - 60 °C | | Operating relative humidity (H-H) | 0 - 80% | | Width | 115 mm | | Depth | 115 mm | | Height | 87 mm | | Diameter | 11.5 cm | | Weight | 835 g | | Package width | 143 mm | | Package depth | 132 mm | | Package height | 173 mm | | Package weight | 835 g | | Package type | Box | | Number of cameras | 1 | | Screws included | Y | | Resource CD | Y | | Harmonized System (HS) code | 85258900 | | Master (outer) case width | 270 mm | | Master (outer) case length | 350 mm | | Master (outer) case height | 580 mm | | Master (outer) case gross weight | 15.6 kg | | Products per master (outer) case | 16 pc(s) |
|
|
