Manufacturer: LEVELONE

Level One LevelOne Antenne panel direktional innen/außen 2.4GHz 18dBi

€171.82 incl tax

SKU: ST08136828

Manufacturer part number: WAN-2182

Manufacturer Homepage

Warranty: 24 months

Stock *

Stock	Delivery	Quantity	Price
LV	7 - 12 days	13	€171.82 incl tax
PL	8 - 15 days	13	€274.59 incl tax

Qty:

Specifications

Products specifications

1
Details 2

WRL stadarti	802.11b
WRL stadarti	802.11n
WRL stadarti	802.11g
WRL stadarti	802.11ac

Status

7 dienas

Description

The LevelOne WAN-2182 is a directional antenna for increased performance and reduced interference, operating on the 2.4 GHz frequency. WAN-2182 can be mounted either indoors or outdoors. The antenna’s gain value is 18dBi, and if mounted outdoors the weatherproof housing can withstand temperatures from minus 30°C up to 60°C, as well as rain, snow, dust and other harsh conditions. - Provides 18dBi directional operation - Directional operation provides extended point to point coverage - For IEEE 802.11b/g/n/ac Wireless applications in 2.4GHz frequency range - Low wind loading - 40°C to 70°C operating temperature range

Antenna gain level (max)	18 dBi
Frequency band	2.4 GHz
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Impedance	50 Ω
Horizontal beam width	25.8°
Vertical beam width	20.7°
Antenna type	Directional antenna
Antenna connector type	N-type
Polarization	Vertical polarization
Voltage Standing Wave Ratio (VSWR)	2.0
Protection features	Dust resistant, Snow resistant, Water resistant
Survival wind speed	180 km/h
Purpose	Indoor & outdoor
Maximum cable loss with connectors	-10 dB
Country of origin	Taiwan
Product colour	Grey
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95%
Width	295 mm
Depth	330 mm
Height	35 mm
Weight	1.04 kg
Package width	333 mm
Package depth	354 mm
Package height	84 mm
Package weight	1.79 kg
Mounting kit	Y
Quick installation guide	Y
Package type	Box
Harmonized System (HS) code	85177100
Master (outer) case width	460 mm
Master (outer) case length	690 mm
Master (outer) case height	370 mm
Master (outer) case gross weight	19 kg
Products per master (outer) case	10 pc(s)

Products specifications

1
Details 2

WRL stadarti	802.11b
WRL stadarti	802.11n
WRL stadarti	802.11g
WRL stadarti	802.11ac

Status

7 dienas

Description

Antenna gain level (max)	18 dBi
Frequency band	2.4 GHz
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Impedance	50 Ω
Horizontal beam width	25.8°
Vertical beam width	20.7°
Antenna type	Directional antenna
Antenna connector type	N-type
Polarization	Vertical polarization
Voltage Standing Wave Ratio (VSWR)	2.0
Protection features	Dust resistant, Snow resistant, Water resistant
Survival wind speed	180 km/h
Purpose	Indoor & outdoor
Maximum cable loss with connectors	-10 dB
Country of origin	Taiwan
Product colour	Grey
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95%
Width	295 mm
Depth	330 mm
Height	35 mm
Weight	1.04 kg
Package width	333 mm
Package depth	354 mm
Package height	84 mm
Package weight	1.79 kg
Mounting kit	Y
Quick installation guide	Y
Package type	Box
Harmonized System (HS) code	85177100
Master (outer) case width	460 mm
Master (outer) case length	690 mm
Master (outer) case height	370 mm
Master (outer) case gross weight	19 kg
Products per master (outer) case	10 pc(s)
