| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 16 |
| SFP module slots quantity | 2 |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Port mirroring | Y |
| Full duplex | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| MAC address auto-learning supported | Y |
| MAC address auto-aging supported | Y |
| VLAN support | Y |
| Virtual LAN features | Tagged VLAN |
| Number of VLANs | 32 |
| MAC address table | 8000 entries |
| Switching capacity | 36 Gbit/s |
| Number of queues | 4 |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Packet buffer memory | 4.1 MB |
| IGMP snooping | Y |
| Multicast support | Y |
| Rack mounting | Y |
| Product colour | Black |
| LED indicators | Activity, Link, PoE, Power, System |
| Country of origin | China |
| Flash memory | 2 MB |
| Noise level | 30 dB |
| Fanless | N |
| Mean time between failures (MTBF) | 43800 h |
| Master (outer) cases per pallet (air) | 20 pc(s) |
| Pallet gross length | 80 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 159.4 cm |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 250 W |
| Surge protection | Y |
| Surge protection voltage | 8 kV |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 230 W |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 81.89 BTU/h |
| Width | 440 mm |
| Depth | 190 mm |
| Height | 44.5 mm |
| Weight | 2.4 kg |
| Cables included | AC |
| Quick start guide | Y |
| Package type | Box |
| Rack mount kit | Y |
| Package width | 503 mm |
| Package depth | 270 mm |
| Package height | 85 mm |
| Package weight | 3 kg |
| Sustainability compliance | Y |
| Sustainability certificates | CE, RoHS |
| Master (outer) case net weight | 750 g |
| Master (outer) case width | 515 mm |
| Master (outer) case length | 360 mm |
| Master (outer) case height | 290 mm |
| Master (outer) case gross weight | 12.8 kg |
| Products per master (outer) case | 4 pc(s) |
