Model | Z890M RIPTIDE WIFI |
CPU socket | LGA1851 |
Processor family | Intel Core Ultra |
Integrated CPU | No |
Chipset manufacturer | Intel |
Chipset type | Intel Z890 |
Memory type | DDR5 |
Number of DDR5 slots | 4 |
Memory bus frequency | 9066 MHz |
Memory bus frequency | 4400 MHz |
Memory bus frequency | 4800 MHz |
Memory bus frequency | 5600 MHz |
Memory bus frequency | 5800 MHz |
Memory bus frequency | 6800 MHz |
Max memory size | 256 (GigaBajt) |
Expansion slots | 1 x M.2 |
Expansion slots | 1 x PCIe 5.0 x 16 |
Max. number of SATA devices | 4 |
Max. number of ATA devices | 0 |
RAID | Yes |
Detailed data on disk/drive interfaces | CPU: - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* Chipset: - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes* - 4 x SATA3 6.0 Gb/s Connectors |
Graphics | - Intel Xe LPG Graphics Architecture
- 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
- 2 x Intel Thunderbolt 4, support HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
|
Sound card | - 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
- Nahimic Audio
|
Network interface | Bluetooth |
Network interface | 1 x 10/100/1000/2500 Mbit/s |
Network interface | Wi-Fi 802.11a/b/g/n/ac/ax |
Network interface | LAN - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
- Killer E3100G
- Supports Killer LAN Software
- Supports Killer DoubleShot Pro
Wireless LAN - 802.11axe Wi-Fi 6E Module
- Supports IEEE 802.11a/b/g/n/ac/ax/axe
- Supports Dual-Band 2x2 160MHz with extended 6GHz band* support
- 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
- Supports Bluetooth 5.3
- Supports MU-MIMO
- Supports Killer LAN Software
- Supports Killer DoubleShot Pro
|
USB ports at back panel | 10 |
USB ports on motherboard | 7 |
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports | 6 |
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports | 5 |
FireWire (IEEE 1394) | No |
COM connector / port | No |
LPT connector / port | No |
External connectors | 1 x Flash BIOS Button |
External connectors | 2 x Thunderbolt 4 |
External connectors | 2 x SMA |
External connectors | 1 x DisplayPort |
External connectors | 1 x HDMI |
External connectors | 1 x Line Out |
External connectors | 1 x MIC |
External connectors | 1 x RJ-45 |
External connectors | 1 x S/PDIF |
External connectors | 2 x USB 2.0 |
External connectors | 2 x USB 3.2 Gen 2 Type-A |
External connectors | 4 x USB 3.2 Gen 1 Type-A |
Onboard connectors | 2 x Addressable LED |
Onboard connectors | 2 x 4pin wentylator CPU |
Onboard connectors | 1 x 4pin CPU/Water Pump Fan Connector |
Onboard connectors | 3 x 4pin Chassis fan |
Onboard connectors | 1 x 4-pin water-pump-fan |
Onboard connectors | 2 x 8pin 12V |
Onboard connectors | 1 x 24pin ATX zasilanie |
Onboard connectors | 2 x USB 2.0/1.1 header |
Onboard connectors | 1 x USB 3.2 Gen 1 Type-A |
Onboard connectors | 1 x USB C |
Onboard connectors | 1 x TPM header |
Onboard connectors | 1 x Front panel audio header |
Onboard connectors | 1 x Power LED and Speaker Header |
Onboard connectors | 1 x RGB LED strip header |
Onboard connectors | 1 x Thermistor Cable Header |
BIOS | 256Mb AMI UEFI Legal BIOS with GUI support |
Form factor | micro ATX |
Dimensions | 24.4 cm x 24.4 cm |
Accessories included | - 2 x kable danych SATA
- 2 x anteny ASRock WiFi 2,4/5/6 GHz
- Kabel rozdzielający ARGB
- Kabel termistora
|
Supported operating systems | Windows 11 |
Software | Software - ASRock Motherboard Utility (Phantom Gaming Tuning)
- Killer Control Center
- ASRock Polychrome SYNC
UEFI - ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Auto Driver Installer
- ASRock Instant Flash
|
Other information | Certyfikaty - FCC, CE
- ErP/EuP ready (wymagany zasilacz ErP/EuP ready)
|
Width | 300 |
Height | 270 |
Depth | 60 |
Weight | 1571 |
Description |
PHANTOM GAMING Z890M Riptide WiFi Riptide został nazwany na cześć specyficznego rodzaju prądu wodnego z silnymi falami, który występuje w oceanie, reprezentując filozofię dwustronnego, spokojnego i nieograniczonego potencjału morza. Zbudowany wokół potężnych funkcji związanych z grami, Riptide dał potężny cios i zanurzył użytkowników w poczuciu stabilności. - Obsługuje procesory Intel Core Ultra (seria 2) (LGA1851)
- 16+1+1+1+1 faza zasilania, 80A Dr.MOS dla VCore+GT+SA
- 4 x DDR5 DIMM
- Obsługuje Dual Channel, do 9066+ (OC)
- 1 PCIe 5.0 x16
- Opcje wyjścia graficznego: 1 HDMI, 1 DisplayPort, 2 Thunderbolt 4 Type-C
- Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio
- 4 SATA3
- 1 Blazing M.2 (PCIe Gen5 x4)
- 1 Hyper M.2 (PCIe Gen4 x4)
- 1 Hyper M.2 (PCIe Gen4 x4 i SATA3)
- 2 Thunderbolt 4 Type-C (tył)
- 1 USB 3.2 Gen2x2 Type-C (przód),
- 2 USB 3.2 Gen2 Type-A (tył),
- 6 USB 3.2 Gen1 (4 z tyłu, 2 z przodu),
- 6 USB 2.0 (2 z tyłu, 4 z przodu)
- Zabójcza sieć LAN 2.5G
- 802.11axe Wi-Fi 6E + Bluetooth
- Obsługuje BIOS Flashback, Memory OC Shield, kondensatory 20 tys. o pojemności 1000 uF
|
