2.4 GHz | Yes |
5 GHz | No |
Maximum data transfer rate | 300 Mbit/s |
Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
Ethernet LAN data rates | 10,100 Mbit/s |
Frequency band | 2.4 - 2.4835 GHz |
Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x |
Cabling technology | 10/100Base-T(X) |
Automatic channel selection | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
VLAN support | Yes |
Virtual LAN features | SSID-based VLAN assignment |
Rate limiting | Yes |
Wireless isolation | Yes |
Quality of Service (QoS) support | Yes |
Transmitting power (CE) | 21 dBm |
Receiver sensitivity | 300M: -71dBm@10% PER
150M: -75dBm@10% PER
54M: -78dBm@10% PER
11M: -93dBm@8% PER
6M: -92dBm@10% PER
1M: -96dBm@8% PER |
Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SNMPv2, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
MAC address filtering | Yes |
Service Set Identifier (SSID) features | Multiple SSIDs |
Number of SSID supported | 8 |
Remote Authentication Dial-In User Service (RADIUS) | Yes |
Access Control List (ACL) | Yes |
Web-based management | Yes |
Syslog | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Power over Ethernet (PoE) | Yes |
AC input voltage | 24 V |
Power consumption (typical) | 2.8 W |
Placement | Ceiling, Wall |
Product colour | White |
Reset button | Yes |
LED indicators | Power |
Certification | FCC, RoHS |
Antenna type | Internal |
Antenna direction type | Omni-directional |
Antennas quantity | 2 |
Antenna gain level (max) | 4 dBi |
Width | 189.4 mm |
Depth | 172.3 mm |
Height | 29.5 mm |
Package type | Box |
Number of products included | 1 pc(s) |
PoE adapter included | Yes |
Cables included | AC |
Mounting kit | Yes |
Quick start guide | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
Harmonized System (HS) code | 85176990 |
Description |
TP-Link EAP110. Maximum data transfer rate: 300 Mbit/s, Maximum data transfer rate (2.4 GHz): 300 Mbit/s, Ethernet LAN data rates: 10,100 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SNMPv2, SSH, WPA, WPA-PSK, WPA2-Enterprise,..., Service Set Identifier (SSID) features: Multiple SSIDs. AC input voltage: 24 V, Power consumption (typical): 2.8 W. Placement: Ceiling, Wall, Product colour: White, LED indicators: Power. Antenna type: Internal, Antenna direction type: Omni-directional, Antenna gain level (max): 4 dBi |
