Superior Wi-Fi Speeds with MU-MIMO Technology
Outfitted with the latest 802.11ac Wave 2 MU-MIMO technology, the EAP225 easily delivers dual-band Wi-Fi speeds of up to 1350 Mbps to multiple devices at the same time.
Cloud Centralized Management
- Anytime, Anywhere
Omada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Facebook check-in and SMS authentication expands your social influence in secured ways
Captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Multiple PoE Options for Easy Installation
EAP225 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE injector, making deployment effortless and flexible.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
Meet Our New Hero Product!
The OC200 Omada Hardware Controller is dedicated to providing centralized management for the whole Omada network.
| | Ethernet WAN | Y | | DSL WAN | N | | SIM card slot | N | | 3G/4G USB modem compatibility | N | | Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) | | Top Wi-Fi standard | Wi-Fi 5 (802.11ac) | | WLAN data transfer rate (max) | 867 Mbit/s | | Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) | | WLAN data transfer rate (first band) | 300 Mbit/s | | WLAN data transfer rate (second band) | 867 Mbit/s | | Ethernet LAN | Y | | Ethernet LAN interface type | Gigabit Ethernet | | Ethernet LAN data rates | 10,100,1000 Mbit/s | | Cabling technology | 10/100/1000Base-T(X) | | Networking standards | IEEE 802.3af | | Mobile network generation | 4G | | 3G | N | | 4G | N | | Ethernet LAN (RJ-45) ports | 1 | | USB port | N | | Memory card slot(s) | N | | DC-in jack | Y | | Web-based management | Y | | Quality of Service (QoS) support | Y | | Reset button | Y | | Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK | | Guest access | Y | | Product type | Portable router | | Product colour | White | | Wall mountable | Y | | Indication light | Y | | LED indicators | Power, WLAN | | On/off switch | Y | | AC adapter included | Y | | Manual | Y | | Quick installation guide | Y | | Quick start guide | Y | | Antenna design | Internal | | Transmit power | CE:≤20dBm(2.4GHz,EIRP), ≤23dBm(5GHz,EIRP), FCC:≤24dBm(2.4GHz), ≤22dBm(5GHz) | | Power source type | AC | | Output voltage | 12 V | | Output current | 1.5 A | | Power supply | 10.15 W | | Operating temperature (T-T) | 0 - 40 °C | | Storage temperature (T-T) | -40 - 70 °C | | Operating relative humidity (H-H) | 10 - 90% | | Storage relative humidity (H-H) | 5 - 90% | | Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP | | Linux operating systems supported | Y | | Width | 180 mm | | Depth | 180 mm | | Height | 47.5 mm | | Package type | Box | | Number of products included | 1 pc(s) | | Harmonized System (HS) code | 85176990 |
|
|
