LevelOne IEC-2000 is an industrial Gigabit Ethernet media converter with a rugged aluminum case which providing superb heat dissipation. This converter is designed to be mounted on an industrial standard DIN-rail, plus the clearly visible status LEDs provide simple monitoring of port link activity. It also features Link Fault Pass Through in order to alert remote location when link status changes.
Fault Detection
Relay contact sends alert signal when the power failed or a port link disconnected, therefore the system operator can respond quickly. This relay contact can be easily configured with a simple DIP switch.
Transportation Application
Complies with NEMA (National Manufacturers Association) TS1 & TS2 Environmental certified for the Traffic Control Equipment that withstand extreme temperatures, operating voltage and humidity fluctuation, vibration and shock commonly experienced in severe outdoor environments.
High Reliability
All components are built to withstand harsh environment applications without compromise where humidity, temperature variation and even shock vibration are concerns, including Electric & Utility, Critical Infrastructure, Transportation and Surveillance Security. This device operates under -40 to 75 Celsius (-40 to 167 Fahrenheit) temperature.
- Complies with NEMA TS1 & TS2 Environmental requirements for Traffic control equipment
- Complies with IEC61000-6-2 EMC Generic standard immunity for Industrial environment
- SFP slot supports pluggable Gigabit optic modules that enabling you to choose from a variety of transceiver
- DIP switch configuration for "Link-Fault-Pass-Through," link down alarm, speed, duplex mode
- 1000Mbps-Full-duplex, 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX
- Full wire-speed forwarding rate
- Alarms for power and port link failure by relay output
- 40°C to 75°C (-40°F to 167°F) operating temperature range, tested for functional operation @ -40°C to 85°C (-40°F to 185°F)
- IP30 aluminum case
- Supports DIN-rail installation
| | Maximum data transfer rate | 1000 Mbit/s | | Converter input interface | 10Base-T, 100Base-TX, 1000Base-TX | | Converter output interface | 1000Base-LX, 1000Base-SX | | Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z | | Ethernet interface type | Gigabit Ethernet | | Ethernet LAN data rates | 10,100,1000 Mbit/s | | Packet forwarding rate (1 Gbps) | 1488100 pps | | Auto MDI/MDI-X | Y | | Auto-negotiation | Y | | Duplex system | Full, Half | | Fiber optic connector | SFP | | Connectivity technology | Wired | | Ethernet LAN (RJ-45) ports | 1 | | Fiber ports quantity | 1 | | Mean time between failures (MTBF) | 665760 h | | Internal | N | | LED indicators | Activity, Link, Power, Status | | Product colour | Black | | Housing material | Aluminium | | International Protection (IP) code | IP30 | | DIN rail mounting | Y | | Country of origin | Taiwan | | Safety | UL508 | | Certification | - ISO9001
- FCC Part 15, Class A
- EN61000-6-3
- EN55022
- EN61000-3-2
- EN61000-3-3
- EN61000-6-2
- EN61000-4-2
- EN61000-4-3
- EN61000-4-4
- EN61000-4-5
- EN61000-4-6
- EN61000-4-8
- IEC60068-2-6 Fc
- IEC60068-2-27 Ea
- FED STD 101C Method 5007.1 | | Input voltage | 12 - 48 V | | Output current (48V) | 0.16 A | | Power consumption (max) | 7.68 W | | Width | 50 mm | | Depth | 110 mm | | Height | 135 mm | | Weight | 800 g | | Operating temperature (T-T) | -40 - 75 °C | | Storage temperature (T-T) | -40 - 85 °C | | Operating relative humidity (H-H) | 5 - 95% | | Package width | 198 mm | | Package depth | 92 mm | | Package height | 236 mm | | Package weight | 1 kg | | Package type | Box | | Quick installation guide | Y | | Harmonized System (HS) code | 85176990 |
|
|
