| Model | B450M-HDV R4.0 |
| CPU socket | Socket AM4 |
| Processor family | AMD Ryzen |
| Integrated CPU | No |
| Chipset manufacturer | AMD |
| Chipset type | AMD Promontory B450 |
| Memory type | DDR4 |
| Number of DDR4 slots | 2 |
| Memory bus frequency | 3200 MHz |
| Memory bus frequency | 2933 MHz |
| Memory bus frequency | 2667 MHz |
| Memory bus frequency | 2133 MHz |
| Memory bus frequency | 2400 MHz |
| Max memory size | 32 (GigaBajt) |
| Expansion slots | 1 x PCIe 2.0 x 1 |
| Expansion slots | 1 x PCIe 3.0 x 16 |
| Max. number of SATA devices | 4 |
| Max. number of ATA devices | 0 |
| RAID | Yes |
| Detailed data on disk/drive interfaces | 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 |
| Graphics | - Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU
- DirectX 12, Pixel Shader 5.0
- Shared memory default 2GB. Max Shared memory supports up to 16GB.
- Three graphics output options: D-Sub, DVI-D and HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz
- Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP 1.4 with DVI-D and HDMI Ports
- Supports 4K Ultra HD (UHD) playback with HDMI Port
|
| Sound card | - 7.1 CH HD Audio (Realtek ALC887 Audio Codec)
- Supports Surge Protection
- ELNA Audio Caps
|
| Network interface | 1 x 10/100/1000 Mbit/s |
| Network interface | - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111H
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE
|
| USB ports at back panel | 6 |
| USB ports on motherboard | 6 |
| Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports | 6 |
| Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports | 0 |
| FireWire (IEEE 1394) | No |
| COM connector / port | Yes |
| LPT connector / port | No |
| External connectors | 1 x HDMI |
| External connectors | 1 x Line In |
| External connectors | 1 x Line Out |
| External connectors | 1 x MIC |
| External connectors | 1 x RJ-45 |
| External connectors | 2 x USB 2.0 |
| External connectors | 4 x USB 3.0 |
| External connectors | 1 x D-Sub |
| External connectors | 1 x DVI-D |
| External connectors | 1 x PS/2 Keyboard/MouseCombo |
| Onboard connectors | 1 x USB 3.0 header |
| Onboard connectors | 1 x 4pin 12V power |
| Onboard connectors | 1 x 24pin ATX zasilanie |
| Onboard connectors | 4 x SATA III 6Gb/s |
| Onboard connectors | 2 x USB 2.0/1.1 header |
| Onboard connectors | 1 x 4pin CPU fan |
| Onboard connectors | 1 x 4pin Chassis fan |
| Onboard connectors | 1 x 3pin Chassis fan |
| Onboard connectors | 1 x Front panel audio header |
| Onboard connectors | 1 x Serial port header |
| Onboard connectors | 1 x TPM header |
| Onboard connectors | 1 x Chassis intrusion header |
| Special functions | Software - ASRock A-Tuning
- ASRock XFast LAN
UEFI - ASRock Full HD UEFI
- ASRock Instant Flash
- ASRock Easy RAID Installer
|
| BIOS | - 128Mb AMI UEFI Legal BIOS with multilingual GUI support
- Supports "Plug and Play"
- ACPI 5.1 compliance wake up events
- Supports jumperfree
- SMBIOS 2.3 support
- DRAM Voltage multi-adjustment
|
| Form factor | micro ATX |
| Dimensions | 23.0 cm x 20.1 cm |
| Accessories included | - Przewodnik użytkownika
- Płyta CD
- I/O Shield
- Kabel SATA Data x 2
- Montaż M.2 x 2
|
| Supported operating systems | Windows 10 |
| Software | Sterowniki, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar |
| Width | 240 |
| Height | 275 |
| Depth | 58 |
| Weight | 743 |
| Description |
Płyta główna B450M-HDV R4.0 AM4 2DDR4 VGA/DVI/HDMI/M.2 uATX |
