| Switch type | Managed |
| Switch layer | L2/L3/L4 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| ARP inspection | Y |
| System event log | Y |
| MIB support | Y |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Port mirroring | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Spanning tree protocol | Y |
| Fast leave | Y |
| VLAN support | Y |
| Virtual LAN features | Tagged VLAN, Port-based VLAN |
| Fiber ethernet cabling technology | 1000BASE-X |
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Forwarding rate | 14.9 Mpps |
| Store-and-forward | Y |
| Number of queues | 8 |
| Jumbo frames support | Y |
| Jumbo frames | 10000 |
| Packet buffer memory | 4.1 MB |
| DHCP features | DHCP client |
| Access Control List (ACL) | Y |
| Access Control List (ACL) ingress | 256 |
| IGMP snooping | Y |
| Security algorithms | SSH, SSH-2, SSL/TLS |
| MAC address filtering | Y |
| Static port security | Y |
| Loop protection | Y |
| BPDU filtering/protection | Y |
| Root protection | Y |
| Password protection | Y |
| DoS attack prevention | Y |
| Authentication type | HWTACACS+, RADIUS |
| CPU defense | Y |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| Neighbor discovery snooping | Y |
| Multicast Listener Discovery (MLD) snooping | Y |
| Management protocols | SNMP v1/v2c/v3, Telnet |
| IPv4 & IPv6 features | IPv6 ping, IPv6 tracert, IPv6 Telnet, Dual stack IPv4/IPv6 |
| Rack mounting | Y |
| Product colour | Black |
| Reset button | Y |
| LED indicators | Activity, Link, Power, System |
| Country of origin | China |
| Safety | UL |
| Certification | CE class A, FCC, VCCI, BSMI |
| Internal memory | 16 MB |
| Firmware upgradeable | Y |
| Plug and Play | Y |
| Mean time between failures (MTBF) | 118824 h |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 80 W |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 70 W |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 267.95 BTU/h |
| Width | 294 mm |
| Depth | 180 mm |
| Height | 44 mm |
| Weight | 2 kg |
| Cables included | AC |
| Quick start guide | Y |
| Package type | Box |
| Rack mount kit | Y |
| Resource CD | Y |
| Package width | 375 mm |
| Package depth | 270 mm |
| Package height | 85 mm |
| Package weight | 2.18 kg |
| Harmonized System (HS) code | 85176990 |
